20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm

20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm

Product Details:

Place of Origin: Tianjin, China
Brand Name: ACE
Certification: BV or LR certified

Payment & Shipping Terms:

Minimum Order Quantity: 1 pieces
Price: $11,300.00/units 1-1 units
Delivery Time: within 30 days
Get Best Price Contact Now

Detail Information
Type: Offshore Frame Containers Length (feet): 20'
Capacity: 30.8 CBM External Dimensions(l X W X H)(mm): 6058 X 2438 X 2896 Mm
Internal Dimensions(l X W X H)(mm): 5812 X 2130 X 2492 Mm Color: Customized
Material: Corten Steel Sling: 4 Legs/5 Legs
Floor: Steel Floor Application: Transportation/Storage/Maintenence

Product Description

20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm 0
Hot Sale Products
Product Datasheet
Specifications
DNV 2.7-1 20ft HC Offshore Frame Container
External Dimensions(L x W x H)
6.058 x 2.438 x 2.896 m
Inside Cubic Capacity
30.8 CBM
Maximum Cargo Weight
16800 KG
Tare Weight
3200 KG
Lifting Angle
45 degree
Customizations
Color, hot dip galvanizing
1. Approval by Main Classification Society: BV / LR
2. Complies With DNV 2.7-1 and ISO18055 Standard
3. Surface Treatment: High Anti-Corrosion Painting or Hot Deep Galvanized
4. Design Temperature: - 20 ℃ (Also provide - 40 ℃ Design)
Product Description

Quality Control & Certificate & Warranty

1) DNV2.7-1 Certificate issued by BV or LR or DNVGL and Sling Certificate.(When there is sling)
2) General Arrangement Drawing.
3) Manufacturing Records, like material certificate, WPS & PQR.
4) Inspection reports of NDT, Dimensions, Loading, Lifting, Painting.
20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm 1

DNV 2.7-1 Standard 20ft HC Offshore Lifting Frame
DNV2.7-1DNV2.7-2
DNV2.7-3
EN12079
A60/H60 Standard
Main Post and Rail: Square
Tube Floor: Steel
Roof: Non Slip
Lifting: Sling via Pad Eyes
Higher Grade Anti-corrosive Paint
Main Structure Materials
Welding & Welder Qualification
2 / 4 Points Lifting
Quick Drop testing
Dimensions & Surface Treatment
20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm 2
20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm 3
20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm 4
20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm 5
20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm 6
20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm 7
20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm 8
Our Advantages
20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm 9
20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm 10
20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm 11
20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm 12
20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm 13
Contact Us
20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm 14

Want to Know more details about this product
I am interested in 20ft High Cube Offshore Frame DNV 2.7 Standard Dry Container for Cargo and External Dimensions of 6058 x 2438 x 2896 mm could you send me more details such as type, size, quantity, material, etc.
