Product Details:

Place of Origin: Tianjin, China
Brand Name: ACE
Certification: BV or LR certified

Payment & Shipping Terms:

Minimum Order Quantity: 1 pieces
Price: $21,000.00/units 1-1 units
Delivery Time: within 30 days
Get Best Price Contact Now

Detail Information
Type: Offshore Reefer Containers Length (feet): 10'
Capacity: 11.86 CBM External Dimensions(l X W X H)(mm): 2991 X 2438 X 2591 Mm
Internal Dimensions(l X W X H)(mm): 2390 X 2294 X 2165 Mm Design Standard: DNV2.7-1 & EN12079
Cooling Unit Brand: Daikin/Thermo King/Carrier Material: Corten Steel/Q345D
Padeye: Included Inner Material: HGSS
Floor: Aluminium T-Bar Floor Power: 380/460V, 3 Phase, 50/60Hz
Sling: Optional

Product Description

10ft Offshore Refrigerated Container CSC/BV Certificates Made of Steel and Aluminium with Aluminium T-Bar Floor 0
Hot Sale Products
Product Datasheet
Specifications
DNV 2.7-1 10ft Offshore Reefer Container
External Dimensions (L x W x H)
2991 x 2438 x 2591 mm
Inside Cubic Capacity
11.86 cbm
Maximum Cargo Weight
7220KG
Tare Weight
2780KG
Lifting Angle
45 degree
Main circuit
3 Phase
AC440, 460V /380, 400, 415V
60/50HZ
DNV 10ft reefer container is designed with pad eye as per DNV2.7-1 and EN12079 standard, which is used on oil and gas offshore platform to storage and transport food from onshore to offshore.

Since the size is same as standard container, and it's with pad eye, so it's very easy to move via trailer and lifting.

Usually, offshore container design temperature is -20 ℃ / -40 ℃.
Product Description

Quality Control & Certificate & Warranty

1) DNV2.7-1 Certificate issued by BV or LR or DNVGL and Sling Certificate.(When there is sling)
2) General Arrangement Drawing.
3) Manufacturing Records, like material certificate, WPS & PQR.
4) Inspection reports of NDT, Dimensions, Loading, Lifting, Painting.
10ft Offshore Refrigerated Container CSC/BV Certificates Made of Steel and Aluminium with Aluminium T-Bar Floor 1

DNV 2.7-1 Standard 10ft Offshore Reefer Container
DNV2.7-1DNV2.7-2
DNV2.7-3
EN12079

A60/H60 Standard
Main Post and Rail: Square
Tube Floor: Steel
Roof: Non Slip
Lifting: Sling via Pad Eyes
Higher Grade Anti-corrosive Paint
Main Structure Materials
Welding & Welder Qualification
2 / 4 Points Lifting
Quick Drop testing
Dimensions & Surface Treatment
10ft Offshore Refrigerated Container CSC/BV Certificates Made of Steel and Aluminium with Aluminium T-Bar Floor 2
10ft Offshore Refrigerated Container CSC/BV Certificates Made of Steel and Aluminium with Aluminium T-Bar Floor 3
10ft Offshore Refrigerated Container CSC/BV Certificates Made of Steel and Aluminium with Aluminium T-Bar Floor 4
10ft Offshore Refrigerated Container CSC/BV Certificates Made of Steel and Aluminium with Aluminium T-Bar Floor 5
10ft Offshore Refrigerated Container CSC/BV Certificates Made of Steel and Aluminium with Aluminium T-Bar Floor 6
Our Advantages
10ft Offshore Refrigerated Container CSC/BV Certificates Made of Steel and Aluminium with Aluminium T-Bar Floor 7
10ft Offshore Refrigerated Container CSC/BV Certificates Made of Steel and Aluminium with Aluminium T-Bar Floor 8
10ft Offshore Refrigerated Container CSC/BV Certificates Made of Steel and Aluminium with Aluminium T-Bar Floor 9
10ft Offshore Refrigerated Container CSC/BV Certificates Made of Steel and Aluminium with Aluminium T-Bar Floor 10
10ft Offshore Refrigerated Container CSC/BV Certificates Made of Steel and Aluminium with Aluminium T-Bar Floor 11
