40ft Length Thermo King Freezer Refrigerated Container Internal Dimensions 11979 x 2294 x 2554 mm
Product Details:
| Place of Origin: | Tianjin, China |
| Brand Name: | ACE |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pieces |
|---|---|
| Price: | $19,000.00/units 1-1 units |
| Delivery Time: | within 30 days |
|
Detail Information |
|||
| Type: | Reefer Container | Length (feet): | 40' |
|---|---|---|---|
| Capacity: | 68cbm | External Dimensions(l X W X H)(mm): | 12192 X 2438 X 2896 Mm |
| Internal Dimensions(l X W X H)(mm): | 11979 X 2294 X 2554 Mm | Reefer Units: | Thermo King |
| Inside Temperature: | -30°C / -22F Deg | Optional Reefer: | Carrier / Daikin |
| Liner Material: | Stainless Steel / Alumimum | Power Supply: | 3 Phase, 380 440V |
Product Description
Hot Sale Products
Product Details
40FT High Cube Reefer Container
Thermo King (US)
Cooling gas: R134a
400 to 500 Vac 3ph 60 Hz
360 to 460 Vac 3ph 50 Hz
Temperature Range:
-40℃ (-40F) to 30℃ (86F).
Carrier(US)
Cooling gas: R134a
380/460 VAC 3ph 50/60Hz
24 VAC control circuit
Temperature Range:
-30℃ (-22F) to 30℃ (86F).
Daikin (Japan)
Cooling gas: R134a
380/440VAC 3ph 50/60Hz
24 VAC control circuit
Temperature Range:
-30~50°C (-22~122°F)
TK Compressor, R404A gas
Power Cable 18mm
Aluminum T Floor
Refer Container Cable Plug
CSC Plate
Thermo King MP4000 Controler
Product Spefications
Specification | ||||||
10ft | 20ft | 40ft HC | ||||
External Size(mm) | 2991x2438x2591 | 6058x2438x2591 | 12192x2438x2896 | |||
Internal Size(mm) | 2389x2294x2273 | 5468x2294x2273 | 11590x2294x2554 | |||
Door Opening(W*H) | 2290x2264mm | 2290x2264mm | 2290x2569mm | |||
Inside Cubic Capacity | 12.5 | 28.4 | 67.9 | |||
Maximum Gross Weight | 15000 | 30480 | 34000 | |||
Tare Weight | 2600 | 2900 | 4560 | |||
Maximum Payload | 12400 | 27580 | 29440 | |||
Allowable Stacking Weight | 86400 | 216000 | 216000 | |||
Cooling Capacity /W | 6300/5580 AT -18℃ Inside/ 38℃ Outside 60/50HZ | |||||
3 PHASE AC 440, 460V/380, 400, 415 60/50HZ | ||||||
Consumption /KW | MAX 13.5 60HZ | |||||
Heat Leakage | 23 | |||||
Air Leakage | 5 | |||||
Packing & Delivery
For Brand New 40 feet thermo king Reefer Container Shipment
1. If you have cargo to load into the container
You could directly pick container up from our yard, and loading goods in factory, and delivery them to port together.
This is the best way to save time and cost for you.
2.Only Empty Reefer Container
Shipping it as empty SOC via container vessel shipping.
Booking Space via picture, CSC plate, Certification.
1. If you have cargo to load into the container
You could directly pick container up from our yard, and loading goods in factory, and delivery them to port together.
This is the best way to save time and cost for you.
2.Only Empty Reefer Container
Shipping it as empty SOC via container vessel shipping.
Booking Space via picture, CSC plate, Certification.
Our Company
ACE Container is a professional Container & Parts supplier in China, which has over 10 years experience in this line, 6 years Golden Member in Alibaba, Trade Assurance Service in Alibaba. Also ACE Container has exported products to over 55 countries.
• Our Main Business Line: Reefer Container Price, All kinds of Dry Cargo Container, Reefer Container, Off shore Container, Dry Container Parts and Container Lashing Equipment.
• Our Main Market: USA, Canada, Southeast Asia, Australia, New Zealand, Middle East, Middle and West Europe.
• Our Main Business Line: Reefer Container Price, All kinds of Dry Cargo Container, Reefer Container, Off shore Container, Dry Container Parts and Container Lashing Equipment.
• Our Main Market: USA, Canada, Southeast Asia, Australia, New Zealand, Middle East, Middle and West Europe.
