13 Ton Axle Alex Thermo King Refrigerator 53ft Insulated Van Box Semi-Trailer Truck Trailers for Transportation Needs
Product Details:
| Place of Origin: | Tianjin, China |
| Brand Name: | ACE |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pieces |
|---|---|
| Price: | $56,000.00/pieces 1-1 pieces |
| Delivery Time: | within 30 days |
|
Detail Information |
|||
| Use: | Truck Trailer | Type: | Semi-Trailer |
|---|---|---|---|
| Material: | Steel | Size: | 40ft, 12391 X 2480 X 1515 Mm |
| Max Payload: | 40ton | Axle: | 13 Ton Fuwa/BPW/CIMC |
| Tire: | 11R22.5 | Color: | As Per Customer's Requirement |
| Landing Gear: | Standard 28Ton | Brake System: | ABS Optional |
| Main Beam: | Q345B Steel | Leaf Spring: | 7 Pcs |
Product Description
Hot Sale Products
Product Description
2/3 Axles Refrigerator Van Semi Trailer
Product Datasheet
Specifications_Refrigerator Semi Trailer: | ||
1. External Size | 14000 x 2550 x 3189 mm (L x W x H) | |
2. Tare weight | 7500 kgs | |
3. Payload | 35 tons | |
4. Inside dimension | 13750 x 2340 x 1500 mm | |
5. Axle | 13 ton Fuwa brand, 150x150, 2/3 units | |
6. Capacity | 70CBM | |
7. Landing gear | Jost E100 | |
8.Kingpin | JOST 2’’ | |
9. Tire | 385/65R22.5 7pcs | |
10. Rim | 22.5 x 11.75 7pcs | |
11. Suspension | Front with Air suspension and rear three 3 axles mechanical suspension | |
12. Elec system | Can change to 12V as per your request | |
13. Braking system | Glad hand valve, Wabco relay valve, 30/30 double brake chambers on rear axle, 30 single chambers on other axles | |
14. Electrical system | Dual circuit, 7-way split pin receptacle plug, LED light | |
15. Painting | Primer coat+ top coat after sand blasting, color according to Customer’s requirement | |
16. Mudguard | Plastic or steel | |
17. Others | 1 tool box, 1 wheel carrier, excluding spare wheel | |
If need other more information, please feel free to contact us, we will reply you soon. Click Here!
Packing & Delivery
There is no packaging requriement for refrigerated semi-trailer, shpping via RORO vessel.
Our Company
ACE Container & Parts Co., Limited, which is very famous and professional Container and Parts supplier in China, and have been container line for many years, also have exported our product to 85 countries by the end of 2018, including Japan, Korea, Southeast Asia, Europe, North and South America, Africa etc.
