| Place of Origin: | Tianjin, China |
| Brand Name: | ACE |
| Minimum Order Quantity: | 1 pieces |
|---|---|
| Price: | $20,000.00/units 2-3 units |
| Delivery Time: | within 30 days |
|
Detail Information |
|||
| Type: | Offshore Tank Container | Length (feet): | 6ft-7ft |
|---|---|---|---|
| Capacity: | 3-5 Cbm | External Dimensions(l X W X H)(mm): | 1800 X 1800 X 2591mm |
| Internal Dimensions(l X W X H)(mm): | 3000 To 5000L | Name: | DNV Offshore Tank |
| Material: | SPA-H (Corten-A) | Tare Mass (Nominal): | 3300KGS |
| Max. Payload: | 16700KGS | Test Pressure: | 0.4 Mpa |
| Temperature: | -40℃ For Tank Body | Stacking: | 1 High For Transport |
| Finish: | Weld Seam: Acid Cleaning And Passivation | Lifting Angle: | 45℃ |
Type | 4000L offshore tank | 8000L offshore tank |
External(m) | 2.268 x 2.268 x 2.500 | 2.991 x 2.438 x 2.591 |
Inside Cubic Capacity(L) | 4000 | 8000 |
Maximum Gross Weight(KG) | 10000 | 20000 |
Tare Weight(KG) | 2400 | 3300 |
Maximum Payload(KG) | 7600 | 16700 |
Lifting Angle | 45 degree | 45 degree |
Design pressure | 0.267 Mpa | 0.267 Mpa |
Text pressure | 0.4 Mpa | 0.4 Mpa |
Temperature | -40℃ for tank body | -40℃ for tank body |
Stacking | 1 high for transport | 1 high for transport |
Material | 316L for tank body | 316L for tank body |
Classification Society | BV / DNV / LR | BV / DNV / LR |
ACE Container & Parts Co., Limited, which is very famous and professional Container and Parts supplier in China, and have been container line for over 10 years, also have exported our product to 55 countries by the end of 2015, including Japan, Korea, Europe, America, Africa etc.
Main business:
Acid Offshore tank container, Liquid ISO container, ISO Dry Container, Reefer Container, Offshore Equipment, All kinds of Container Parts and Customized Special Container.
