10 pcs of Offshore IBC tanks are loaded into one 40ft HC Container.
 |
2000L DNV 2.7-1 Standard Offshore Steel IBC Tank Container Condition and CSC Certified for Offshore Applications
Product Details:
| Place of Origin: | Tianjin, China |
| Brand Name: | ACE |
| Certification: | DNV2.7-1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pieces |
|---|---|
| Price: | $6,900.00/pieces 2-4 pieces |
| Delivery Time: | within 30 days |
|
Detail Information |
|||
| Type: | Offshore Container | Length (feet): | 1500 |
|---|---|---|---|
| Capacity: | 2000L | External Dimensions(l X W X H)(mm): | 1500 X 1160 X 2340 Mm |
| Internal Dimensions(l X W X H)(mm): | 2000L | Color: | Optional |
| Material: | Corten-A | Age: | Brand New |
| CSC Certified: | Yes | Sling: | DNV 2.7-1 Standard |
| Approval Area: | Offshore Oil And Gas Platform | Sling Angle: | 45 Degree |
Product Description
Hot Sale Products
Product Description
2000L 550GAL Offshore IBC Tank Container More information as follows:
Corner Casting: SCW480
Shell:SS304
Welding Technique: Automatic TIG welding (Tungsten Inert Gas arc welding).
Surface treatment: Painted or Galvanized
Special for transportation and storage of offshore freight.
Meeting DNV 2.7-1 & ISO10855 standard.
Classification Society: BV, LR, DNV certified
Design Temperature: -20°c
Surface treatment: Painted or Galvanized
Special for transportation and storage of offshore freight.
Meeting DNV 2.7-1 & ISO10855 standard.
Classification Society: BV, LR, DNV certified
Design Temperature: -20°c
Product Spefications
Type | 2000L offshore IBC tanks | |||
External Size | 1500 x 1160 x 2340 | MM | ||
External Dimension Tank | 1257 x 1105 x 1924 | MM | ||
Capcity | 2000 | L | ||
Maximum Gross Weight | 5000 | KGS | ||
Tare Weight | 580 | KGS | ||
Maximum Payload | 4420 | KGS | ||
Design Pressure | 0.267 | Mpa | ||
Tesing Pressure | 4.0 | Mpa | ||
Lifting Angle | 45 | degree | ||
Frame Material | SPA-H,Q345D | |||
Tank Shell | SS304 | |||
Stacking | No stacking | |||
Finish | Customized color | |||
Special Features: | ||||
1. Approval by Main Classification Society: LR | ||||
2. Complies With DNV2.7-1:2006 and ISO10855, IMDG | ||||
3. Working Pressure: Atmospheric Pressure | ||||
4. Tank Thickness: 3mm | ||||
5. Manhole: 567mm EPDM Rubber | ||||
6. Outlet: 2'' NPT | ||||
7. Level Gauge: 1/2'' | ||||
Packing & Delivery
Offshore IBC Tanks
10 pcs of Offshore IBC tanks are loaded into one 40ft HC Container.
Certifications
Our Advantages
FAQ
1. Are your offshore IBC tanks brand new?
Yes, we only do brand new offshore container.
2. Can choose the color and logo?
Sure, we can do it as per your requirement.
3. Are there any certification and testing report for dnv offshore chemical tanks?
Yes, there will be DNV2.7-1 certification issued by LR/BV, also have other testing report and certification. For example, NDT testing report, Size Testing, Loading inspection, Mill Certification, Welder Certification etc.
4. How to arrange the shipping?
10 pcs loaded into one 40ft HC Container.
5. How about the production date?
It's about 55 days after getting your deposit.
Yes, we only do brand new offshore container.
2. Can choose the color and logo?
Sure, we can do it as per your requirement.
3. Are there any certification and testing report for dnv offshore chemical tanks?
Yes, there will be DNV2.7-1 certification issued by LR/BV, also have other testing report and certification. For example, NDT testing report, Size Testing, Loading inspection, Mill Certification, Welder Certification etc.
4. How to arrange the shipping?
10 pcs loaded into one 40ft HC Container.
5. How about the production date?
It's about 55 days after getting your deposit.
6. Do you also supply offshore tank in other capacity?
Yes, we also can do 2900L, 4500L，8200L and others as per your requirement.
