Product Details:

Place of Origin: Tianjin, China
Brand Name: ACE

Payment & Shipping Terms:

Minimum Order Quantity: 1 pieces
Price: $12,000.00/pieces 1-1 pieces
Delivery Time: within 30 days
Get Best Price Contact Now

Detail Information
Type: Dry Container Length (feet): 20'
Capacity: 33.5 Cbm External Dimensions(l X W X H)(mm): 6058 X 2438 X 2896 Mm
Internal Dimensions(l X W X H)(mm): 5898 X 2288 X 2477 Mm Color: Choose
Material: Corten Steel Approval: BV GL Certified
Logo: As Per Your Requirement Product Name: 20ft Dnv Offshore Container
Design Temp.: -20℃ Floor: Steel Floor
Surface Treatment: Hot Dip Galvanized

Product Description

6058 x 2438 x 2896 mm DNV 2.7-1 Standard Open Side Door High Cube Offshore Container with Corten Steel and Side Opening Door 0
Hot Sale Products
Product Description
6058 x 2438 x 2896 mm DNV 2.7-1 Standard Open Side Door High Cube Offshore Container with Corten Steel and Side Opening Door 1
We will provide full set of Offshore Container Documents
1) DNV2.7-1 Certificate issued by BV or LR or DNVGL and Sling Certificate.(When there is sling)
2) General Arrangement Drawing
3) Manufacturing Records, like material certificate, WPS & PQR.
4) Inspection reports of NDT, Dimensions, Loading, Lifting, Painting.
DNV 2.7-1 Standard 20ft High Cube Open Side Offshore Container
Structure Material: JIS SPA-H/ GB Q345D,E36
Corner Casting: SCW480
Welding Technique: Automatic TIG welding ( Tungsten Inert Gas arc Welding ).
Surface treatment: Painted or Galvanized
Special for transportation and storage of offshore freight.
Meeting DNV 2.7-1 & EN12079 standard.
Classification Society: BV, LR, DNV certified
Design Temperature: -20°c
6058 x 2438 x 2896 mm DNV 2.7-1 Standard Open Side Door High Cube Offshore Container with Corten Steel and Side Opening Door 2
6058 x 2438 x 2896 mm DNV 2.7-1 Standard Open Side Door High Cube Offshore Container with Corten Steel and Side Opening Door 3
20ft Offshore Frame
6058 x 2438 x 2896 mm DNV 2.7-1 Standard Open Side Door High Cube Offshore Container with Corten Steel and Side Opening Door 4
20ft Offshore Container
6058 x 2438 x 2896 mm DNV 2.7-1 Standard Open Side Door High Cube Offshore Container with Corten Steel and Side Opening Door 5
Product Datasheet
Specifications
20ft Side Opening Offshore Container

Dimensions
(L x W x H)
External
6.058 x 2.438 x 2.896

M
20 x 8 x 9.5

FT
Internal
5.898 x 2.280 x 2.477

M
Inside Cubic Capacity
33.50

CBM
Maximum Gross Weight
15000

KG
Tare Weight
3700

KG
Maximum Payload
11300

KG
Lifting Angle
45 degree

1. Approval by Main Classification Society: BV / LR
2. Complies With DNV 2.7-1 and ISO18055 Standard
3. Surface Treatment: High Anti-Corrosion Painting or Hot Deep Galvanized
4. Design Temperature: - 20 ℃ (Also provide - 40 ℃ Design)
Quality Control & Certificate & Warranty
We will provide full set of Offshore Container Documents
1) DNV2.7-1 Certificate issued by BV or LR or DNVGL and Sling Certificate.(When there is sling)
2) General Arrangement Drawing
3) Manufacturing Records, like material certificate, WPS & PQR.
4) Inspection reports of NDT, Dimensions, Loading, Lifting, Painting.

6058 x 2438 x 2896 mm DNV 2.7-1 Standard Open Side Door High Cube Offshore Container with Corten Steel and Side Opening Door 6
